PARKER T12 Dobbelt Slagvolumen Bent-akse Motorer T12-60 T12-80

The T12 two-displacement motor is tailor-made for track drives. It allows a high ratio between high and low speed and installs as easily as a fixed displacement motor. Max speed ratio is 3.33-to-1. The T12 is a cartridge motor based on the well proven V12 series. The specially designed end cap with dual side ports permits a very short installation. A simple setting device moves the cylinder barrel to the maximum orminimum displacement position. The setting is controlled by an external hydraulic pilot signal. A brake valve can be fitted without increasing the axial length of the motor. The twin ports have the samemounting pattern as those of the F12 and V12 motors. The F12/V12 accessory valve program also fits the T12 motor. As an option, integrated pressure relief valves can be included.Benefits/Features• Designed for Track drive applications the 3.33 to 1 speed ratio provides versatility• Cartridge mount allows very short installation dimension• Optional valve blocks do not add to length F12/V12 accessory valves will fit T12 motor
